Outdoor advertising LED display

1. Light weight

2.High brightness

3.High protection

4.Ultra thin

5. Wide viewing angle

Model No.	W2.5	W3	W4	W5	W6.6	W8	W10
Pixel Pitch (mm)	2.5	3.076	4	5	6.67	8	10
LED Type	SMD1415	SMD1415	SMD1921	SMD1921	SMD3535	SMD3535	SMD3535
Module Dimension (W*H) (mm)	320*160	320*160	320*160	320*160	320*160	320*160	320*160
Module Resolution (W*H) (Pixel)	128*64	104*52	80*40	64*32	48*24	40*20	32*16
Pixel Density (Pixel/m²)	160000	105625	62500	40000	22500	15625	10000
Cabinet Dimension (W*H) (mm)	960*960	960*960	960*960	960*960	960*960	960*960	960*960
Cabinet Resolution (W*H) (Pixel)	384*384	312*312	240*240	192*192	144*144	120*120	96*96
Cabinet Material	Magnesium Alloy	Magnesium Alloy	Magnesium Alloy	Magnesium Alloy	Magnesium Alloy	Magnesium Alloy	Magnesium Alloy
Cabinet Weight (Kg)	25	25	25	25	25	25	25
Best Viewing Distance (m)	2.5	3	4	5	6.6	8	10
Brightness (Nits)	5000-10000	5000-10000	5000-10000	5000-10000	5000-10000	6000-10000	6000-10000
Ingress Protection (Front/ Rear)	IP65	IP65	IP65	IP65	IP65	IP65	IP65
Max Power Consumption (W/㎡)	800	800	800	800	800	800	800
Average Power Consumption (W/m²)	350	350	350	350	350	350	350
Refresh Rate (Hz)	1920-3840	1920-3840	1920-3840	1920-3840	1920-3840	1920-3840	1920-3840
Input Power	AC 100-240V, 50-60Hz	AC 100-240V, 50-60Hz	AC 100-240V, 50-60Hz	AC 100-240V, 50-60Hz	AC 100-240V, 50-60Hz	AC 100-240V, 50-60Hz	AC 100-240V, 50-60Hz
Operating Temp/ Humidity (℃/ RH)	-30℃-80℃, 10%-90%	-30℃-80℃, 10%-90%	-30℃-80℃, 10%-90%	-30℃-80℃, 10%-90%	-30℃-80℃, 10%-90%	-30℃-80℃, 10%-90%	-30℃-80℃, 10%-90%

Key Specification of outdoor LED display
