Outdoor Front Maintenance LED Sign/ Billboard
1. Front maintenance
2. 2ft x 1ft module size
3. High brightness
4. Energy saving
5. IP67 waterproof
IP67 High Brightness Outdoor Front Service LED Sign
IP67 High Brightness Outdoor Front Service LED Sign
Specifications of Outdoor Front Service LED sign/ billboard
| Model No. | K4 | K6 | K9 |
|---|---|---|---|
| Pixel Pitch (mm) | 4.233 | 6.35 | 9.525 |
| LED Type | SMD 1921 | SMD 2727 | SMD 2727 |
| Module Dimension (W*H) (ft) | 1*1 | 1*1 | 1*1 |
| Module Resolution (W*H) (Pixel) | 144*72 | 96*48 | 64*32 |
| Pixel Density (Pixel/m²) | 55808 | 24800 | 11022 |
| Cabinet Dimension (W*H) (ft) | 4*2 | 4*2 | 4*2 |
| Cabinet Resolution (W*H) (Pixel) | 288*144 | 192*96 | 128*64 |
| Cabinet Material | Aluminum | Aluminum | Aluminum |
| Cabinet Weight (Kg) | 24 | 24 | 24 |
| Best Viewing Distance (m) | 4.2 | 6.3 | 9.5 |
| Brightness (Nits) | 7000-10000 | 7000-10000 | 7000-10000 |
| Maintenance Method | Front/ Rear | Front/ Rear | Front/ Rear |
| Ingress Protection (Front/ Rear) | IP67 | IP67 | IP67 |
| Max Power Consumption (W/㎡) | 630 | 630 | 630 |
| Average Power Consumption (W/m²) | 210 | 210 | 210 |
| Refresh Rate (Hz) | 3840 | 3840 | 3840 |
| Input Power | AC 100-240V, 50-60Hz | AC 100-240V, 50-60Hz | AC 100-240V, 50-60Hz |
| Operating Temp/ Humidity (℃/ RH) | -30℃-80℃, 10%-90% | -30℃-80℃, 10%-90% | -30℃-80℃, 10%-90% |
Key Specification of Outdoor Front Service LED sign/ billboard
|
Pixel Pitch (mm)
|
4.233, 6.35, 9.535
|
|---|---|
|
Cabinet Dimension |
2*4ft, 2*2ft |
|
Maintenance Method |
Front/ Rear |
|
Brightness (Nits) |
6000-10000 |
|
IP Grade |
IP67 |
